- Range up to 200 m
- ± 1.0 mm accuracy, 0.1 mm resolution
- Measuring slopes
- Smart Horizontal Mode
- Fast start-up time
- Foldable end-piece with automatic detection
- Bright and clear 2.4” IPS display with scratch-proof lens
- Trigger measurements with gestures
- Memory for 50 measurements
- Li-Ion rechargeable battery
- USB-C charging
- Keyboard Mode, simulating data-transfer via Bluetooth®
- Bluetooth® 5.0 Technology for error-free data transfer
- Works with DISTO Plan App (iOS and Android) and DISTO transfer (Windows)
Berat | 1 kg |
---|
Specifications
Leica DISTO D5 | |
Accuracy with favourable conditions * | 1.0 mm / 1/16″ *** |
Accuracy with unfavourable conditions ** | 2.0 mm / 1/8″ *** |
Range with favourable conditions * | 0.05 – 200 m / 0.07 – 660 ft *** |
Range with unfavourable conditions ** | 0.05 – 120 m / 0.07 – 400 ft *** |
Smallest unit displayed | 0.1 mm / 1/32 in |
X-Range Power Technology | yes |
Laser Class 2 | 635 nm, <1 mW |
Digital Pointfinder with 4-fold zoom | yes |
Tilt measuring range **** | 360° |
Tilt measuring tolerance | ± 0.2° |
ø laser point | at distances | 6 / 30 / 60 mm | 10 / 50 / 100 m |
Protection class | IP54 (dust- and splash water protected) |
Auto. laser switch off after | 90 s |
Auto. power switch off after | 180 s |
Bluetooth® Smart | Bluetooth® v5.0 |
Range of Bluetooth® | up to 10 m |
Battery durability (Li-Ion 2 000 mAh) | up to 5’000 measurements up to 10 hours operation time |
Dimension (H x D x W) | 144 x 60 x 24 mm | 5.7 x 2.4 x 0.9 in |
Weight (with batteries) | 180 g / 6.35 oz |
Temperature range storage | operation | -25 to 70 °C / -13 to 158 °F | -10 to 50 °C / 14 to 122 °F |
* favourable conditions: white and diffuse reflecting target (white painted wall), low background illumination and moderate temperatures.
** unfavourable conditions: targets with lower or higher reflectivity or high background illumination or temperatures at the upper or lower end of the specified temperature range.
*** Tolerances apply from 0.05 m to 10 m with a confidence level of 95%. Above 5 m the tolerance may deteriorate according to the values given in the manual of the unit.
**** after user calibration. Additional angle related deviation are according to the values given in the manual of the unit.
Includes
- Leica DISTO D5 laser distance meter
- Hand loop
- Pouch
- USB cable
- Safety instructions
- Calibration Certificate Silver
- Quick Start with QR code linking to online manual
- 3 Years warranty card
