Total Station Alpha X
Total Station ALPHA X dengan Surpro 6.0 untuk Proyek Teknik
ALPHA X adalah Total Station generasi terbaru dengan desain kompak, dilengkapi kompensator dua sumbu (Dual-axis compensator), keyboard alfanumerik, serta layar LCD 6 baris x 20 karakter. Dengan tambahan tombol trigger, proses pengukuran menjadi lebih mudah dan cepat.
Dilengkapi bluetooth bawaan, ALPHA X memungkinkan koneksi dengan data controller dan perangkat lunak Surpro 6.0, sehingga pekerjaan survey topografi menjadi lebih efisien dan praktis.
Fitur Unggulan ALPHA X
- Akurasi Tinggi Menjamin pengukuran sudut dan jarak yang presisi, sangat penting dalam pengambilan data untuk proyek konstruksi dan teknik sipil.
- Desain Ringkas & Tahan Lama Struktur yang kompak dan kokoh, cocok untuk berbagai kondisi kerja di lapangan.
- Perangkat Lunak SurPro 6.0 Software berbasis Android yang mudah digunakan, mempercepat proses pengumpulan, pemrosesan, dan analisis data.
- Pengukuran Tanpa Reflektor (Reflectorless Measurement) Mampu mengukur jarak tanpa prisma, meningkatkan jangkauan dan fleksibilitas dalam berbagai medan.
- Konektivitas Data Canggih Dilengkapi bluetooth dan opsi konektivitas lainnya untuk transfer data yang cepat dan seamless ke berbagai sistem.
| Berat | 1 kg |
|---|
Specifications
| Telescope | Length | 156mm |
| lmage | Erect | |
| Objective aperture | Telescope:Ф45mm(meas.dist.:Ф50mm) | |
| Magnification | 30x | |
| Field of view | 1°30′ | |
| Shortest focus distance | 1.0m | |
| Angle measurement | Reading system | Absolute encoder |
| Angle unit | 360°/400gon/6400mil,selectable | |
| Display resolution | 1″/5″/10″(or 0.2mgon/1mgon/2mgon) | |
| Accuracy*1 | 2″/5″ | |
| Distance measurement | Laser class(lEC60825-1) | Reflectorless: Class 3R |
| Reflective sheet/RP60: Class 3R | ||
| Prism: Class 1 | ||
| Measurement range(Good condition)*2 | ||
| Reflectorless*3 | Reflectorless:1 to 1000m | |
| Reflective sheet/RP6: 01 to 1200m | ||
| Single prism: 1 to 5000m | ||
| Accuracy | Prism: 2mm+2ppm | |
| Reflective sheet/RP60: 2mm+2ppm | ||
| Reflectorless: 2mm+2ppm | ||
| Measuring time | Fine mode: 1.2s | |
| Tracking mode: 0.3s | ||
| Fast mode: 0.7s | ||
| Display resolution(m/inch selectable) | 0.2mm/1mm | |
| Pressure input range | 500hPa to1500hPa(1hPa steps) | |
| Temperature input range | -40°C to+60°C(1°C steps) | |
| Prism constant correction | -99.9mm to+99.9mm | |
| Compensator | Range/Setting accuracy | ±3’/1” |
| Level vial sensitivity | Plate level vial | 30″/2mm |
| Circular level vial | 8’/2mm | |
| Laser plummet(Standard)*4 | Accuracy | ±1mm/1.5m |
| Laser class | Class2/IEC60825-1 | |
| Laser spot brightness | Adjustable | |
| Laser wave length | 635nm | |
| Optical plummet (Factory optional) | Accuracy | ±0.8mm/1.5m |
| lmage | Erect | |
| Magnification | 3x | |
| Field of view | 4° | |
| Focus range | 0.5m to ∞ | |
| Power | Battery | 3400mAh Li-ion Rechargeable |
| Output voltage | 7.4V DC | |
| Continuous operation time | Approx.20 hours(At +20°C) | |
| (Single distance measurement every 30 seconds) | ||
| Charger | FDJ6-Li(100V/240V) | |
| Charging time(at +20°C) | Approx.4 hours | |
| Application programs | Data collection/Stake out/Resection/REM/MLM | |
| AREA/Point to line/Z coordinate/OFF set | ||
| Others | Display | LCD，6 Lines |
| CPU | 32Bit | |
| Memory | 120000 points,support SD card(Optional) | |
| Keyboard | Alphanumerical key board, both sides | |
| Weight(including batteries) | 5.1kg | |
| Dimensions(WxDxH) | 175x178x340mm | |
| Operating temperature | -20°Cto+50°C | |
| Storage temperature | -40°C to +70°C | |
| Interface | USB/RS-232C/Bluetooth(Factory Optional) | |
| Water and dust protection | IP55 | |
