LEICA DA230 3WATT SIGNAL TRANSMITTER
Rp0 + PPN 11%
Hubungi Kami :
0816 721 791
dexsautama@gmail.com
The Leica DA signal transmitters apply a signal onto underground cables or pipes that may not carry a detectable signal. The Leica DD SMART cable locators can then be used to locate the signal from the Leica DD signal transmitter. The DA signal transmitters are compact, robust and easy-to-use. The have been designed in conjunction with the DD SMART cable locators to easily and accurately avoid, trace or locate buried cables and pipes.
- To improve the detection success.
- To trace the route of a utility.
- To make a depth or current measurement.
| Berat | 3 kg |
|---|
Specifications
| MODE | DD220 SMART | DD230 SMART |
| Power | 50 / 60 Hz mains electrical and harmonics | 50 / 60 Hz mains electrical and harmonics |
| Radio | 15kHz to 60kHz | 15kHz to 60kHz |
| Auto | Power, Radio, 33kHz | Power, Radio, 33kHz |
| Transmitter Modes | 131.072 (131) kHz 32.768 (33) kHz 8.192 (8) kHz | 131.072 (131) kHz 32.768 (33) kHz 8.192 (8) kHz 512 Hz 640 Hz |
| Depth Range | Line 0.1m to 5m Line 4 inches to 16.4 feet Sonde 0.1m to 7m Sonde 4 inches to 23 feet | Line 0.1m to 7m 4 inches to 23 feet Sonde 0.1 to 10m Sonde 4 inches to 32.8 feet |
| Depth Accuracy* | 5% | 5% |
| Bluetooth | Class 2 BLE dual mode module Bluetooth Classic 2.1 Bluetooth 4.0 (LE) | Class 2 BLE dual mode module Bluetooth Classic 2.1 Bluetooth 4.0 (LE) |
| GPS** | Chipset (1): u-blox®GPS Reciever Type: GPS L1C/A, SBAS L1C/A, QZSS L1C/A, GLONASS L1OF, BeiDou B1 Accuracy (2): Horizontal Position 2.5 m Autonomous, 2.0 m SBAS,CEP Start time: Cold 45 s typical, Aided 7 s typical, Hot 1 s typical | Chipset (1): u-blox®GPS Reciever Type: GPS L1C/A, SBAS L1C/A, QZSS L1C/A, GLONASS L1OF, BeiDou B1 Accuracy (2): Horizontal Position 2.5 m Autonomous, 2.0 m SBAS,CEP Start time: Cold 45 s typical, Aided 7 s typical, Hot 1 s typical |
| Memory Capacity | 8 GB internal memory | 8 GB internal memory |
| Environmental Standard | IP66 | IP66 |
| Operating Temperature | -20 °C to +50 °C -4 °F to +122°F | -20 °C to +50 °C -4 °F to +122°F |
| Battery | 7.4V Rechargeable Li – Ion | 7.4V Rechargeable Li – Ion |
| Battery operating time *** | 15 h | 15 h |
| Dimensions (HxWxD) | 765×290 x93mm 30.12 x11.42×3.66 inches | 765×290 x93mm 30.12 x11.42×3.66 inches |
| *Depth to an undistorted signal ** (1) All data/information according to manufacturer u-blox®GPS; Leica Geosystems does not assume any liability whatsoever for such information. (2) Accuracy is dependent upon various factors including atmospheric conditions, multipath, obstructions, signal geometry and number of tracked satellites. *** Constant use at 20°C/68°F | ||
