Nikon NE-100

- Four models to choose from: NE-100/101/102/103
- Accurate, affordable, easy to use
- Ergonomic keypad
- One-touch function keys
- Large, backlit LCD display
- NE-100/101 models are water-resistant
- NE-102/103 models are waterproof
- 5″, 7″ and 10″ accuracies available

FEATURES & BENEFITS

Four models to choose from: NE-100/101/102/103
Accurate, affordable, easy to use
Ergonomic keypad
One-touch function keys
Large, backlit LCD display
NE-100/101 models are water-resistant
NE-102/103 models are waterproof
5″, 7″ and 10″ accuracies available

OVERVIEW

Designed for general construction and survey applications, Nikon NE-100 Series electronic digital theodolites give you accurate measurements in an affordable, easy-to-use platform. Each of the four models has an ergonomic keypad with one-touch keys for all functions, and a large backlit LCD display helps you work productively in the field.

You can instantly convert vertical angles to percent of grade, reset the horizontal angle to zero and lock the horizontal angle displayed on the LCD while you reposition or repeat a measurement. Angle accuracies differ between the models. The NE-100 offers 10″ angle accuracy, while the NE-101 offers 7″. Both the NE-102 and 103 models offer 5″ angle accuracy with the NE-103 featuring vertical axis compensation NE-102 and NE-103 also have a rear display and keypad.

NE-100 series theodolites feature five easy-to-use, one-touch keys: four to perform all common functions and a fifth to control the backlit LCD display and reticle illumination. NE-100 Series theodolites feature a built-in reticle illuminator and backlit LCD display that allow you to work inside buildings as well as in tunnels, mines and other environments with little or no light. These features also come in handy during low light conditions outdoors, such as near dawn or dusk.

Unlike other instruments that require specialized batteries, NE-100 Series theodolites use six standard AA batteries. What’s more, those batteries can power all models for about 48 hours. A three-level bar graph on the LCD screen displays remaining battery power.

With the Nikon NE-100 Series theodolite models, you can count on reliable performance in tough conditions. The NE-100/101 models have an IP54 rating, meaning water can splash on them from any direction with no harmful effects. Nikon NE-102/103 models have a higher rating of IP56 which means they’re waterproof and dustproof.

Specifications

Telescope
Image	Erect
Magnification	30x
Diameter of Objective Lens (Aperture)	1.77 in. (45 mm)
Focus Distance	2.3 ft. (0.7 m)
Field of View	1°20′
Ratio of Stadia Lines	100/0
Resolving Power	N/A
Length of Tube	N/A
Reticule Illumination	Yes
Quick Sites (Rough Sites)	N/A

Optical Plummet
Image	Erect
Magnification	2.2x
Field of View	5°
Focus Range	4.3 ft. (1.3 m) Fixed

Angle Measurement
Minimum Reading	10/20″ or 5/10″; 2/5 mgon or 1/2 mgon; 0.02/0.05 mil
Unit of Reading/Measure	Degree / gon / mil
Display	N/A
Accuracy	7 second or 10 second (NIKON-NE-100)
Circle Diameter	N/A
Measuring Method/Reading System	N/A
Detection Method	N/A

Level
Plate/Tubular Bubble Vial	40 second / 2 mm
Circular Bubble Vial	10 minutes / 2 mm
Electronic Vial	N/A

General
Weight	9.8 lbs (4.5 kg)
Warranty	2-year
Dimensions	13.15″ H x 6.04″ W x 6.8″ D (334 mm x 153.5 mm x 172 mm)
Protection Class	IP54 dustproof and water splash resistant
Tripod Thread	N/A
Auto Shut Off	N/A
Tribrach	Detachable
Theft Protection	N/A

Battery/Power
Power Source	6 x AA batteries
Battery Life	22 hours manganese batteries/48 hours alkaline batteries
Battery Life Alert	Yes
Voltage	1.5V

Applications
90-Degree Layout	Yes
Checking Angles	Yes
Alignment and Plumb	Yes
Short-Range Leveling	Yes
General Construction	Yes
Anchor Bolt Positioning	Yes
Steel Column Placement	Yes
Setting Elevations	Yes
Setting Lines	Yes
Basic Grade Work	Yes

Display and Keypad
Type	Dot-matrix LCD with 20 characters x 2 lines
Sides	Single
Keys	5-button keypad
Touchscreen	N/A
Backlight	Yes
Pixels	N/A

Temperature
Operating	-4 to 122 °F (-20 to 50 °C)
Storage	N/A

Tilt Sensor/Compensator
Range	N/A
Type	N/A
Method	N/A
Setting Accuracy	N/A

Laser Plummet
Accuracy	N/A
Class	N/A
Wavelength	N/A

Laser Pointer
Accuracy	N/A
Range Indoors	N/A
Class	N/A
Wavelength	N/A
Range Outdoors	N/A

Interface
Bluetooth	N/A
USB	N/A
Pin Port	N/
